Rack cabinet 19 inch rack dimensions pdf. Light duty economy 19 rack mount table top cabinet choice of three depths 13 330 mm 17 5 445 mm and 24 5 622 mm rails are fixed both front and rear round hole punched for 10 32 clip nuts to full eia hole centers 5 8 5 8 1 2 inch spacing. A rack s mounting fixture consists of two parallel metal strips referred to as rails standing vertically. Only 1 left in stock order soon. The 19 inch dimension includes the edges or ears that protrude from each side of the equipment allowing the module to be fastened to the rack frame with screws.

33 48 of over 1 000 results for 19 inch rack dimensions navepoint 9u deluxe it wallmount cabinet enclosure 19 inch server network rack with locking perforated door 24 inches deep black. 19 rack equipment dimensional data as specified by bs5954 1980 and iec 297 1975. The front rack opening must be 451 mm wide 0 75 mm 17 75 in. Startech cabshelfv1u 1u rack shelf 10 deep steel vented rack shelf rack mount shelf server rack shelf cantilever shelf.

0 03 in apart on center horizontal width between vertical columns of holes on the two front mounting flanges and on the two. Single and double gang electrical plate dimensions. A 19 inch rack is a standardized frame or enclosure for mounting multiple electronic equipment modules. 19 rack specification a rack s mounting fixture consists of two parallel metal strips referred to as rails standing vertically.

19 rack mounting 84 overall height dnrr2377hdwb 44u 23 rack mounting 77 overall height dnrr2384hdwb 48u 23 rack mounting 84 overall height light duty relay rack weight capacity up to 1 200 lbs single tapped welded. The rails are separated by a gap of 450 mm 17 72 inch and are a minimum of 16 7 mm 0 657 inch wide giving an overall rack width of 482 6 mm or 19 as the name suggests. 0 03 in and the rail mounting holes must be 465 mm 0 8 mm 18 3 in. Free shipping by amazon.

19 rack equipment dimensional data. The rack or cabinet must meet the eia standard eia 310 d for 19 inch racks. Rack cabinet solutions.
